21
Vertiv I Liebert LPC I User Manual
2 Installation
The Installation process consists of the following procedures, namely -
• Pre-installation
• Installation Preparation
• Mechanical Installation
• Electrical Installation
2.1
Pre-installation
Pre-installation contains the following 3 sub sections, namely -
• Transportation & Movement
• Unpacking
• Inspection
2.1.1 Transportation and Movement
When it comes to transporting the system, Railroad is the most preferable choice. However, if
railroad transportation is not possible, then the truck transport option is an optimal choice.
One precaution is to choose roads that do not have too many bumps and if any, avoid it as
much as possible.
Liebert LPC series of air conditions are on the heavier side and therefore, it is recommended
that equipment such as an electric forklift is utilized for these heavy-duty systems. Move the
equipment to a location which is in the vicinity of the installation site. If an electric forklift is
used, insert the tines of the forklift below the pallet as displayed in Figure 2-1. Align the tines
with the centre of gravity to prevent the equipment from falling over.
Figure 2-1 depicts the way the tines of the forklift are inserted below the pallet and in the
same image, the graphic to the right indicates that the tines are aligned with the center of
gravity to prevent the equipment from falling over:
Figure 2-1 Electric Forklift handling a Liebert LPC system
