VTM-2000 Installation and Operation Handbook
1-1
Section 1 ♦ Introduction
The Videotek VTM-2000 is a Muti-format On-Screen Monitor with waveform
monitor, vectorscope, picture, and alarm status. It is a 19” rackmounted unit that
accepts two NTSC or PAL composite video signals, two SD-SDI video signals, and an
external analog reference video signal. The display presents the image carried by the
selected video input as a real-time, full-motion picture. Front panel user controls allow
for various display and selection modes.
In addition, the VTM-2000 also accepts the audio option VTM-A
3
-OPT 1, which is the
Advanced Audio Analysis Option with bargraphs and lissajous. With the
VTM-A
3
-OPT 1 up to four audio channels can be viewed simultaneously. There are
two analog stereo inputs, four AES/EBU inputs, and 16 channels of embedded audio.
It also contains analog monitoring outputs of up to four channels simultaneously.
The VTM-2000 seamlessly integrates into any broadcast, post-production, camera
maintenance, satellite or cable facility, and is the ultimate choice for quality control,
troubleshooting, or compliance checking applications.
*
US Patents 6,069,607, 6,532,024, and 6,828,981. UK Patent 2,330,475. Other US and foreign patents pending.
Features include:
• Dual SD-SDI inputs with auto detection
• Dual composite analog inputs with auto detection
• Reference input
• XGA, High Resolution, output
• Three user presets and one factory preset
• Compact 1RU configuration
• Input standards: SMPTE 259M-C, NTSC, and PAL
Video Standards Supported
The VTM-2000 supports the following video standards:
For SD:
• 525/59.94
• 625/50
For analog:
• NTSC
• PAL
The VTM-2000 front and back panels are illustrated in Figure 1-1.
