Videotek VTM-2000 - Table 4-8. Video Alarms, Analog Menu

Global Setup Menu Functions
VTM-2000 Installation and Operation Handbook
4-8
Table 4-8. Video Alarms, Analog Menu
OFF (Default) -
ENABLE
ON -
LOSS OF SIGNAL
DURATION
0 TO 60 SECONDS (2
Seconds is Default)
-
OFF (Default) -
ENABLE
ON -
RANGE
5 TO 89 DEGREES (20
DEGREES is Default)
-
SC/H PHASE
DURATION
0 TO 60 SECONDS (2
SECONDS Default)
-
ENABLE -
THRESHOLD NTSC
50 TO 140 IRE (120 IRE
is Default)
THRESHOLD PAL
 51 UNITS TO 143
UNITS (136 UNITS is
Default)
 357 to 1000 mV
(951 mV is Default)
SENSITIVITY
1 CES to 20 CES (2 CES
is Default)
PEAK UPPER
DURATION
0 TO 60 SECONDS (2
SECONDS is Default)
ENABLE -
THRESHOLD NTSC
-40 TO 0 IRE (-20 IRE is
Default)
THRESHOLD PAL
 -41 UNITS TO 0
UNITS (-34 UNITS is
Default)
 -285 to 0 mV (-238
mV is Default)
SENSITIVITY
1 CES to 20 CES (2 CES
is Default)
ANALOG GAMUT
PEAK LOWER
DURATION
0 TO 60 SECONDS (2
SECONDS is Default)
