Videotek VTM-2000 - Center Vector; Standard; Table 3-11. Vector Pane Menu; Vector Position

General Operation
VTM-2000 Installation and Operation Handbook
3-24
Table 3-11. Vector Pane Menu
75%
ANALOG/SD STANDARD
100%
POSITION
USE H POS AND V POS KNOB.
CENTER VECTOR
Press SETUP/ENTER
SETUP
Press SETUP/ENTER
Standard
Standard is used to set the marks on the vector display. The marks on the vector help
to visualize the minimum/maximum value of a video signal. The position of the
excursion marks are 75% or 100% for analog and SD.
Vector Position
The Vector Position can be adjusted by using the UP/DOWN and RIGHT/LEFT knobs.
Center Vector
Centering of the vector can be accomplished by pressing the SETUP/ENTER button.
Vector Setup
Press the SETUP/ENTER access the global Vector setup menu. For more information
on the global Vector Setup menu see Section 4.
