VTM-2000 Installation and Operation Handbook
A-1
Appendix A ♦ Specifications
Video
Inputs A and B (Digital)
Two (2) dual standards inputs accepting Standard definition, SMPTE
259 M-C formats, including: 525/59.94, 625/50
Data Rate
270 MB/s
Connectors
4 BNCs, Hi-Z passive looping
Level
800 mV, nominal
Input EQ
Up to 200 meters of 8281 at 270 MB/S
Return Loss
≤ -15 dB 5 MHz to 270 MHz
Inputs C and D: (Analog)
Two (2) NTSC/PAL composite video auto detect
Signal Level
1V p-p
Input Impedance
Hi-Z, looping
Return Loss
≤ -45 dB 100 kHz to 5 kHz
