Global Setup Menu Functions
VTM-2000 Installation and Operation Handbook
4-3
Table 4-2. Video Format Menu
AUTODETECT (Default) -
625/50 -
VIDEO A CONFIGURE
525/59.94 -
AUTODETECT (Default) -
625/50 -
VIDEO B CONFIGURE
525/59.94 -
AUTODETECT (Default) -
NTSC -
VIDEO C CONFIGURE
PAL -
AUTODETECT (Default) -
NTSC -
VIDEO D CONFIGURE
PAL -
Table 4-3. Waveform Setup Menu
PERCENT
DIGITAL WAVEFORM GRATICULE
VOLTS (Default)
OFF
NTSC PEDESTAL
ON (7.5 IRE) (Default)
UNITS (Default)
PAL WAVEFORM SCALE
VOLTS
OFF
DC RESTORE
ON (SLOW) (Default)
WAVEFORM INTENSITY
25% TO 200% (100% NORMAL)
WAVEFORM CONTRAST
25% TO 200% (100% NORMAL)
PERSISTENCE
NORMAL, 1 TO 6 & INFINITE
(NORMAL is Default)
ATTACK
LOW, 2 TO 6, and MAX (LOW is
Default)
Table 4-4. Vector Setup Menu
NORMAL (Default)
PAL OVERLAY
OVERLAY
OFF (Default)
SD I/Q LINES
ON
VECTOR INTENSITY
25% TO 200% (100% is NORMAL)
VECTOR CONTRAST
25% TO 200% (100% is NORMAL)
PERSISTENCE
NORMAL, 1 TO 6, & INFINITE
(NORMAL is Default)
ATTACK
LOW, 2 TO 6, MAX (LOW is Default)
