Manual VIPA System 200V Chapter 3 Deployment CPU 21x-1Bx06
HB97E - CPU - RE_21x-1Bx06 - Rev. 13/20 3-25
VIPA specific diagnostic entries
You may read the diagnostic buffer of the CPU via the Siemens SIMATIC
manager. Besides of the standard entries in the diagnostic buffer, the VIPA
CPUs support some additional specific entries in form of event-IDs.
To monitor the diagnostic entries you choose the option PLC > Module
Information in the Siemens SIMATIC manager. Via the register "Diagnostic
Buffer" you reach the diagnostic window:
Module information
Diagnostic Buffer
Nr.
8
9
10
11
12
13
Time of day
...
...
13:18:11:370
...
...
...
Date
...
...
19.12.2011
...
...
...
Event
...
...
Event-ID: 16# E0CC
...
...
...
Path: Accessible Nodes MPI = 2 Operating mode CPU: RUN
Details:
...
VIPA-ID
... ... ... ...
... ... ... ... ... ...
The diagnosis is independent from the operating mode of the CPU. You
may store a max. of 100 diagnostic entries in the CPU.
The following page shows an overview of the VIPA specific Event-IDs.
Entries in the
diagnostic buffer
Monitoring the
diagnostic entries
