Vogelsang VX100Q - 5.5 Connection to the power supply; 5.5.1 Electric drive; 5.5.2 Hydraulic drive

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
22/61
Pos: 106 /Übersc hriften/Überschrif t 2 /Anschluss an die Energie versorgung @ 41\mod_127 3568357506_4 8.doc @ 1845 20 @ 2 @ 1
5.5 Connection to the power supply
Pos: 107 /WBV/P umpen/Montag e/Anschluss an di e Energieversorg ung @ 61\ mod_131702 1833515_48.d oc @ 316793 @ @ 1
The geared motor can only be connected to the energy supply after it has been installed in the pipeline.
Pos: 108 /Übersc hriften/Überschrif t 3 /Elektrischer Antrieb @ 6 1\mod_131 7733792548_48.d oc @ 318293 @ 3 @ 1
5.5.1 Electric drive
Pos: 109 /WBV/P umpen/Warn hinweise/Stromge fahr/Elektrisch er Antrieb - el ektrischer Schlag @ 61\mod_1 31702197476 7_48.doc @ 316 824 @ @ 1
Danger of electric shock from pumps with an electrical drive
Only qualified electricians may connect the device to the power supply.
Pos: 110 /WB V/Pumpen/W arnhinweise/Hin weis/Anschließen Getriebemotor @ 61\mo d_131702217 8067_48.doc @ 316884 @ @ 1
Connecting the geared motor (electric motor with gearbox)
@ 39\mod_125 9315210400_6. doc @ 141472 @
Before connecting
check that the power supply is correct for the motor.
Be sure to follow the cable layout diagram on the inside of the motor terminal box cover.
note that the PTC temperature sensor of the geared motor must be connected to the terminals
provided on the pump control, to a PTC actuation unit or to a variable-frequency drive with a PTC
input (each available as an option).
install a repair switch near to the machine (recommendation).
Before start-up or long-term storage
the seal in the bleed screw must be removed in order to prevent excessive pressure build-up in the
gearbox and thus leaks (see the accompanying documentation "Operating instructions – geared
motor”).
Pos: 111 /Übersc hriften/Überschrif t 3 /Hydraulisc her Antrieb @ 61\mod_131 7733834122_4 8.doc @ 3183 22 @ 3 @ 1
5.5.2 Hydraulic drive
Pos: 112 /WBV/P umpen/Warnhin weise/Gefahr/H ydraulischer Antri eb - Inf ektionsgefahr durc h Hydrauliköl @ 61\mod_131 7022066220_ 48.doc @ 316854 @ @ 1
Danger of infection due to hydraulic oil under pressure escaping on pumps with
hydraulic drive
• The connection to the power supply must be done by qualified personnel.
• Leakages can occur due to seal faults.
• Wear protective goggles.
On injuries with hydraulic oil, seek out a doctor immediately!
Pos: 113 /WBV/P umpen/Warnhin weise/Maschi nengefahr/H ydraulikmotoren b ei Pumpen mi t hydraulische m Antrieb @ 61\ mod_1317991 178246_48.doc @ 320129 @ @ 1
Hydraulic motors and hydraulic hose lines
• Before connecting hydraulic hoses, read and follow the manufacturer’s specifications for hydraulic
motors.
• Observe the permissible hydraulic pressure and the permissible delivery rate.
• Replace hydraulic hose lines that show signs of damage or ageing. Only use genuine Vogelsang
hydraulic hose lines of the manufacturer.
• The date of manufacture of the hydraulic hose line is displayed on the pressing component of the
connector. The period of usage for the hydraulic hose line should not exceed 6 years (although 5
years is recommended), including a possible storage period of no more than 2 years.
Pos: 114 /WBV/P umpen/Warn hinweise/Hinweis/ Anschließen Hydr aulikmotor @ 61\mod_ 1317734946024_4 8.doc @ 31835 1 @ @ 1
Installation of hydraulic motor
• When two hydraulic motors are installed, they are operated parallel and the torques of both motors are
added.
