6 Start-up
Pos: 117 /WBV/P umpen/Warnhin weise/Hinweis/ Personal für Inb etriebnahme u nd Betrieb @ 61\mod_1317 987611363_48. doc @ 32007 1 @ @ 1
Personnel for start-up and operation
We recommend starting up the pump in the presence of persons who are responsible for further operation of
the machine.
Pos: 118 /Übersc hriften/Überschrif t 2 /Chec kliste vor Inbetri ebnahme @ 26\m od_12123933 00130_48.doc @ 91833 @ 2 @ 1
6.1 Check list before start-up
Pos: 119 /WBV/P umpen/Inbetrie bnahme/002 Ch eckliste - Inb etriebnahme @ 61\mod_1317 736311218_48. doc @ 31838 1 @ @ 1
 Is the coupling if present correctly aligned?
 Are the cardan shafts, if present, correctly aligned?
 Is the belt tension OK?
 Are the optional buffer chamber assemblies correctly installed? Are they correctly adjusted?
Is the buffer chamber pressure OK?
 Are the type of oil and oil level in the gearbox of the pump OK?
 Is the buffer fluid or quenching fluid OK? Is the fluid level in the buffer chamber OK?
 If equipped with a grease nipple, has the sealing prechamber been greased?
 Have all safety devices been installed and their proper functioning ensured?
 Is the motor connected correctly to the power supply (see documents provided by the motor
manufacturer)?
 Star or delta connection, voltage, frequency (see name plate and inside of terminal box)?
 Motor protection ensured, e.g., by a circuit breaker?
For star-delta starting, if present, a short switching time should be set.
A short start ramp should be set for the soft starter, if present.
 Is the variable-frequency drive/soft starter, if present, designed and configured correctly?
Equipment should be suitable for heavy starting
 Is the motor hydraulically correctly connected?
 Are safety device or repair switch easy to reach?
 Is the direction of flow OK? Check the pump's direction of rotation.
 Is the pipe system sealed and free of leakage?
 Is free flow within the pipe system ensured?
Positive displacement pumps may never be operated in a sealed pipe.
 Are the drain cocks closed, and is the pump filled with fluid?
 Put the pump into operation and check inlet and outlet pressure, speed and capacity.
