7.2 Gearbox
Pos: 163 /Übersc hriften/Überschrif t 3 /Getriebeöl @ 58\mo d_13125398206 22_48.doc @ 308 699 @ 3 @ 1
7.2.1 Gearbox oil
Pos: 164 /WBV/P umpen/Wartung/G etriebe/002 Ta belle Ölme nge Getriebe @ 58\mod_1312540533 042_48.doc @ 3 08728 @ 4 @ 1
7.2.1.1 Gearbox oil quantity
Series
VX100
VX100 with flange-
mounted electric motor**
VX136
VX186
Oil quantity in litres [l]
0.65*
1.3
2
4
* With vertical installation of the series VX00, the gearbox oil quantity is 1 litre instead of 0.65 litres.
** With vertical installation of the series VX100 with flange-mounted electric motor, please request
our “Technical information TINF.PU.019.xx".
Pos: 165 /WBV/P umpen/Wartung/G etriebe/002 Öls orte Getrieb e @ 58\mod_ 13125415020 07_48.doc @ 308758 @ 4 @ 1
7.2.1.2 Gearbox oil grade
Vogelsang standard oil
EP (Extreme Pressure) gearbox oil
SAE class 90 (85W-90)
Part-no. BSS.006
If you need other lubricants, please ask us for a table (TINF lubricants) of alternative oils. Request our
“Technical Information TINF.PU.012.xx".
Pos: 166 /Übersc hriften/Überschrif t 3 /Kontrolle u nd Wechsel des Getriebeöls @ 58\mod_13 12541937886 _48.doc @ 30 8787 @ 3 @ 1
7.2.2 Checking and changing the gearbox oil
Pos: 167 /WBV/P umpen/Warnhin weise/Gefahr/Ha ut- und A ugenreizungen d urch Hilfs-, Betri ebsstoffe und Me dium (Getrie be) @ 62\mod _1319712376 414_48.doc @ 32 5993 @ @ 1
Skin and eye irritation caused by auxiliary materials, operating materials and medium
• To protect against fluids spraying out, carefully and slowly open the gearbox. Cover the valves or
screws to be removed with a cloth or similar item where appropriate.
Pos: 168 /WBV/P umpen/Wartung/G etriebe/002 K ontrolle und Wechsel des Getri ebeöls @ 58\ mod_13125 39457224_48.d oc @ 308669 @ @ 1
 Fig. “Changing gearbox oil"
Gearbox oil
• check and if necessary refill minimum amounts up to the control opening (C). Only refill while the
gearbox is stationary:
every 500 operating hours, at least quarterly
• replace:
After the first 20 operating hours.
Every 2000 operating hours
Changing the buffer or quenching fluid has to be carried out after changing the gearbox oil.  chap. “Buffer
chamber assembly"
 Chap. “Maintenance plan"
Pos: 169 /WBV/P umpen/Warnhin weise/Umwelt/U mweltgerechte Entsorgung - Getriebeöle @ 61\mod_ 13179873074 03_48.doc @ 320042 @ @ 1
Environmentally friendly disposal
Treat gearbox oils like hazardous wastes and dispose of properly.
