VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
Pos: 173 /Übersc hriften/Überschrif t 2 /Abschmi eren des Dicht ungsvorraums @ 0 \mod_1109 928103761_4 8.doc @ 1258 @ 2 @ 1
7.3 Greasing of sealing prechamber
Pos: 174 /WBV/P umpen/Wartung/Di chtungsvorra um abschmi eren/002 nur bei B aureihe VX13 6 und VX186 @ 58\mod_13 12793538196_4 8.doc @ 3088 53 @ @ 1
(only for series VX136 and VX186)
Pos: 175 /WBV/P umpen/Wartung/Di chtungsvorra um abschmi eren/002 Schmierni ppel Intro @ 58\mod_1 312793679022_4 8.doc @ 3088 83 @ @ 1
Grease nipples are primarily used for long-fibred media. They can be retrofitted upon request .
The sealing prechamber can be greased through the grease nipples (if applicable) Fig. "Changing
gearbox oil".
Lubrication prevents the fibrous matter from hardening and adversely affecting the function of the
mechanical seal.
Pos: 176 /WBV/P umpen/Warnhin weise/Maschi nengefahr/Absch mieren bei la ufender Maschine @ 58\mod _1312795680 529_48.doc @ 3 08941 @ @ 1
• A regular lubrication lubrication interval prevents the lubrication channel from clogging.
• To ensure effective distribution of the lubricant, always lubricate while the machine is running and not
when it is stationary.
Pos: 177 /WBV/P umpen/Wartung/Di chtungsvorra um abschmi eren/002 Schmierf ett + Wartungspl an @ 58\ mod_1312793 755364_48.doc @ 308912 @ @ 1
Grease type
Lithium soap grease having a mineral oil base
Renolit GP 2
Designation K2K-30
ISO-L-X-CCEA 2
Part-no. BSS.008
Grease quantity
Grease nipple (gearbox side): 5 shots per nipple with a lube gun
Grease nipple (on the QD cover): 6 shots per nipple with a lube gun
Lubrication interval
Lubricating the 4 grease nipples (gearbox side) Fig. “Changing gearbox oil"
Lubricating the 2 grease nipples (on the QD cover) Fig. “Changing gearbox oil"
• At start up
• Before and after a longer period of removing from service (2-3 weeks)
Chap. “Maintenance plan"
