8.11 Reducing the starting torque
Pos: 247 /WBV/P umpen/Instandse tzung/002 Red uzierung des Anlaufmoments V X100/136/1 86 - Q @ 58\ mod_1312980 850254_48.doc @ 309691 @ 3 3 @ 1
With the series VX100Q, VX136Q and VX186Q, the starting torque can be reduced by installation of thin
wear plates (series …QVVA excepted) or by the installation of shims between rotary lobes and wear plates.
Increasing the gaps between rotary lobes and wear plates however reduces the volumetric efficiency.
8.11.1 Increasing the gap by installing thinner wear plates
(VVA-series excluded)
Increasing the gap ( + 1 mm)
VX136Q
Gear side: Wear plate PFL.B009.T1 (4 mm) replaces wear plate PFL.B009 (5 mm)
Cover side: Wear plate PFL.B002.T1 (3 mm) replaces wear plate PFL.B002 (4 mm)
VX186Q
Gear side: Wear plate PFL.A017.T1 (5 mm) replaces wear plate PFL.A017 (6 mm)
Cover side: Wear plate PFL.A002.T1 (4 mm) replaces wear plate PFL.A002 (5 mm)
Increasing the gap ( + 0.3 mm)
VX136Q
Gear side: Wear plate PFL.B009.T2 (4.7 mm) replaces wear plate PFL.B009 (5 mm)
Cover side: Wear plate PFL.B002.T2 (3.7 mm) replaces wear plate PFL.B002 (4 mm)
VX186Q
Gear side: Wear plate PFL.A017.T2 (5.7 mm) replaces wear plate PFL.A017 (6 mm)
Cover side: Wear plate PFL.A002.T2 (4.7 mm) replaces wear plate PFL.A002 (5 mm)
