VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
Pos: 33 /WBV/pro duktübergreifen d/Sicherheitseinric htungen @ 4 1\mod_12 73236449259_4 8.doc @ 18412 5 @ @ 1
Qualified personnel must connect and check safety devices on a regular basis for proper function, especially
after doing maintenance and repair work, before restarting.
Pos: 34 /WBV/Pu mpen/Warnhi nweise/Gefahr/ Verletzungsgefa hr durch Herabf allen der Pump e @ 59\mo d_13134126436 35_48.doc @ 310 240 @ @ 1
Risk of injury when loading and transporting the pump or the pump unit
• Use the lifting eye bolts on the pumps only for lifting the pump without mounted parts (for example,
the motor).
• The unit may only be transported suspended or screwed to a Euro pallet. Fig. “Transport aids”.
• During loading operations and when setting down the pump or the pump unit, it may be begin to swing
or fall. Risk of crushing! Therefore:
The loading and transporting may only be carried out by specially trained persons.
Standing under raised loads is prohibited. Direct persons out of the danger area.
Pos: 35 /WBV/Pu mpen/Warnhi nweise/Gefahr/ Verletzungsgefa hr durch Stolpern auf rutschige m Untergrund @ 61\mod_1 317048539608_4 8.doc @ 3169 82 @ @ 1
Risk of injury from stumbling on slippery floor
• Keep work station clean and clean up any auxiliary materials, operating materials and medium residue
that may be present, especially before maintenance and repair work on the pump or the pump unit.
• Caution when temperatures are below freezing - keep workplace free of ice.
Pos: 36 /WBV/Pu mpen/Warnhi nweise/Maschin engefahr/Frostg efahr @ 58\ mod_1312293 026339_48.doc @ 308069 @ @ 1
• If there is a risk of frost, drain the pump by running the pump in either direction, until all liquid is
drained out of the pump. Therefore you may use the drain cocks in the connectors.
• For complete emptying, remove the Q or QD cover, Chap. “Opening the Q cover" or “Opening the
QD cover".
• Attention! Before start-up, refill with fluid.
Pos: 37 /WBV/Pu mpen/Warnhi nweise/Maschin engefahr/Hoch viskoses Mediu m @ 58\mo d_1312362219883 _48.doc @ 308 105 @ @ 1
When using the pump for a very viscous medium, the pump speed must be reduced according to the
material's viscosity, to prevent the suction flow from breaking off on the suction side (cavitation protection).
Pos: 38 /WBV/Pu mpen/Warnhi nweise/Maschin engefahr/Gleitri ngdichtung SiC -SiC @ 58\mo d_131227473 7011_48.doc @ 307892 @ @ 1
Pumps with a mechanical seal consisting of the material combination SiC-SiC:
To avoid adhesion of the mechanical seal faces this pump needs to be rotated (at least one revolution) every
two months when not in service.
Pos: 39 /---Seitenumbruch--- @ 21\mod_120 1696136229_ 0.doc @ 8057 5 @ @ 1
