OM 803 us – Edition 3.7 * 803b610.fm 6-15
Technical data
Transverse direction, travel gear extended
2.5 m (98 in) 2.0 m (79 in) 1.5 m (59 in) 1.0 m (39 in)
A max (m/ft) kg/lbs
2.4 m (94 in) 1.41 (4.61) 216 (477) -- -- -- --
2.0 m (79 in) 2.03 (6.64) 167 (367) -- 170(376) -- --
1.5 m (59 in) 2.40 (7.86) 126 (277) -- 172 (378) -- --
1.0 m (39 in) 2.59 (8.49) 109 (240) 116 (255) 166 (366) 247 (544) --
0.5 m (20 in) 2.65 (8.70) 103 (227) 113 (248) 158 (347) 241 (531) --
0.0 m (0.0 in) 2.60 (8.52) 104 (230) 110 (242) 150 (332) 226 (499) 431 (951)
−0.5 m (−20 in) 2.41 (7.91) 115 (253) -- 148 (325) 222 (490) 433 (955)
−1.0 m (−39 in) 2.05 (6.73) 138 (304) -- 149 (328) 225 (497) 418 (922)
