Wacker Neuson 803 - Charging the Battery with the Mains; Charging the Battery with the Power Unit

OM 803 us – Edition 3.7 * 803b340.fm 3-73
Operation
Charging the battery with the power unit
Turn protective cap C counterclockwise and remove it.
Connect safety connector D of the battery charger with the accessories outlet E of the power unit.
Charging the battery with the mains
Connect safety connector D of the battery charger with a 230 V outlet F.
Environment!
Dispose of old batteries in an environmentally friendly manner.
LED working light
The Dual Power option includes an energy-saving LED working light that is switched on
and off with switch A.
A
Fig. 163:
D
C
E
A
Fig. 164:
D
F
Fig. 165:
A
