Operation
Information!
Traveling diagonally on slopes is prohibited.
Change position on level ground and then travel straight-ahead onto the slope.
Traveling uphill
During uphill travel, the control stand must face uphill.
Set the stabilizer blade uphill.
Raise the boom about 20 – 30 cm (8 – 12 in) off the ground and position it straight ahead
at the center of the machine.
Do not exceed a maximum gradient angle of 15°.
Traveling downhill
During downhill travel, the control stand must face downhill.
Set the stabilizer blade downhill.
Raise the boom about 20 – 30 cm (8 – 12 in) off the ground and position it straight ahead
at the center of the machine.
Do not exceed a maximum sloping angle of 15°.
Fig. 61: Traveling diagonally on slopes
Fig. 62: Traveling uphill
< 15°
20 – 30 cm
(8 – 12 in)
20 – 30 cm
(8 – 12 in)
Fig. 63: Traveling downhill
< 15°
