Wacker Neuson 803 - Raising the Rollbar

OM 803 us – Edition 3.7 * 803b330.fm 3-35
Operation
☞Remove the starting key
Information!
In order to lower it, the rollbar must be held by one person on either side.
☞Remove the linch pins and bolts B on either side
☞Slowly and carefully lower the rollbar as far as it will go
Raising the rollbar
☞Stop the machine on firm, level and horizontal ground
☞Stop the engine
☞Raise the lock lever
☞Remove the starting key
Information!
In order to raise it, the rollbar must be held by one person on either side.
☞Slowly and carefully lower the rollbar
Fig. 86: Lowering the rollbar
B
Fig. 87: Rollbar lowered
Fig. 88: Lowering the rollbar
