OM 803 us – Edition 3.7 * 803b110.fm 1-21
Introduction
Meaning
Fuse assignment.
Use only original fuses with the specified current rating!
Position
Behind the right-hand trim
Meaning
The coolant must have a thermal stability of –30 °C (–22 °F).
– see chapter 6.10 Coolant compound table on page 6-9
Position
On the inside of the engine cover
Meaning (option)
Remove the shatter protection if the machine is transported on an open platform.
Position
On the shatter protection at the upper left in traveling direction.
If an additional cross brace is installed (from the 3rd quarter of 2014), the shat-
ter protection does not have to be removed before transporting the machine on
an open platform.
Meaning (option)
Read the Operator’s Manual before connecting lines.
Position
At the rear left.
Fig. 44: Removing the shatter protection
Fig. 45: Dual Power connection
