OM 803 us – Edition 3.7 * 803b320.fm 3-3
Operation
Pos. Description For more information see page
1 Operator seat.....................................................................................................................................................................3-28
2 Upper carriage lock............................................................................................................................................................3-25
3 Engine cover lock ..............................................................................................................................................................3-41
4Starter................................................................................................................................................................................3-10
5 Stabilizer blade/telescopic travel gear lever ..............................................................................................................3-22,3-24
6 Stabilizer blade/telescopic travel gear changeover lever...................................................................................................3-24
7 Boom swivel pedal.............................................................................................................................................................3-53
8 Engine cover
9 Handhold
