WAGO-I/O-SYSTEM 750 Device Description 17
750-461 2AI Pt100/RTD
Manual
Version 1.4.1
Pos: 21.7 /Alle Serien ( Allgemeine Module)/ Überschriften/Ebene 2/ Anschlüsse - Überschr ift 2 @ 4\mod_124098426265 6_21.docx @ 31961 @ 2 @ 1
3.2 Connectors
Pos: 21.8 /Seri e 750 (WAGO-I/O-SYSTEM)/Gerätebeschrei bung (alte Struktur) /Anschlüsse/Datenkon takte/Lokalbus - Überschrift 3 @ 6\mod_125629 4684083_21.docx @ 43660 @ 3 @ 1
3.2.1 Data Contacts/Local Bus
Pos: 21.9.1 /Seri e 750 (WAGO-I/O-SYSTEM)/Gerätebeschr eibung (alte Struktur) /Anschlüsse/Daten kontakte - Feldbu skoppler/-contr oller, Abbildung und Beschr eibung @ 3\mod_123177125 9187_21.docx @ 26002 @ @ 1
Communication between the fieldbus coupler/controller and the I/O modules as
well as the system supply of the I/O modules is carried out via the local bus. It is
comprised of 6 data contacts, which are available as self-cleaning gold spring
contacts.
Figure 2: Data Contacts
Pos: 21.9.2 /Seri e 750 (WAGO-I/O-SYSTEM)/Wichtige Er läuterungen (alte Strukt ur)/Sicherheits- und sonstige Hinweise/ Achtung/Achtung: I/O-Module nicht auf Goldf ederkontakte legen! @ 7\ mod_1266318463636_21. docx @ 50695 @ @ 1
Do not place the I/O modules on the gold spring contacts!
Do not place the I/O modules on the gold spring contacts in order to avoid soiling
or scratching!
Pos: 21.9.3 /Seri e 750 (WAGO-I/O-SYSTEM)/Wichtige Er läuterungen (alte Strukt ur)/Sicherheits- und sonstige Hinweise/ Achtung/Achtung: ESD - Auf gute Erdung der Umgebung ac hten! @ 7\mod_126631853866 7_21.docx @ 50708 @ @ 1
Ensure that the environment is well grounded!
The devices are equipped with electronic components that may be destroyed by
electrostatic discharge. When handling the devices, ensure that the environment
(persons, workplace and packing) is well grounded. Avoid touching conductive
components, e.g. data contacts.
Pos: 21.10 /Dokumenta tion allgemein/Glie derungselemente/---Sei tenwechsel--- @ 3\mod_122110804507 8_0.docx @ 21810 @ @ 1
