WAGO-I/O-SYSTEM 750 Process Image 27
750-461 2AI Pt100/RTD
Manual
Version 1.4.1
Pos: 23 /Alle Serien ( Allgemeine Module)/ Überschriften/Ebene 1/Pr ozessabbild - Überschri ft 1 @ 4\mod_1240983067828_21. docx @ 31942 @ 1 @ 1
4 Process Image
Pos: 24.1 /Serie 750 (W AGO-I/O-SYSTEM)/Prozessabbild Loka lbus/AI/Prozess abbild 750-0461 Einlei tung @ 16\mod_1378299772322_ 21.docx @ 130789 @ @ 1
The I/O module transfers 16 bits per channel of measured data and, optionally, 8
status bits to the fieldbus coupler/controller. Access to the status bits depends on
the specific fieldbus system.
Pos: 24.2 /Serie 750 (W AGO-I/O-SYSTEM)/Prozessabbild Loka lbus/Hinweis: Pr ozessabbildmapping abh ängig von FBK/PFC, mit Stat us-/Controllbyte @ 4\mod _1242621308640_21.doc x @ 33290 @ @ 1
Mapping of process data in the process image of fieldbus systems
The representation of the I/O modules’ process data in the process image
depends on the fieldbus coupler/controller used. Please take this information as
well as the particular design of the respective control/status bytes from the
section “Fieldbus Specific Design of the Process Data” included in the description
concerning the process image of the fieldbus coupler/controller used.
Pos: 24.3 /Serie 750 (W AGO-I/O-SYSTEM)/Prozessabbild Loka lbus/AI/Prozess abbild 750-0461 nach Vari anten @ 5\mod_12514389917 81_21.docx @ 41034 @ 2333233 3233 @ 1
4.1 I/O Modules with Pt Resistance Sensors
Table 16: I/O Modules with Pt Resistance Sensors
Evaluation Pt100
Measuring range: −200 °C to +850 °C
Measuring range: −200 °C to +850 °C
Evaluation Pt100, optimized temperature drift
(0.001 %/K, conversion time 960 ms)
Measuring range: −200 °C to +850 °C
Evaluation Pt100, with status information for
S5-FB250 in the data word
Measuring range: −200 °C to +850 °C
Evaluation Pt100, extended temperature range
Measuring range: −200 °C to +850 °C
4.1.1 Pt100
The I/O modules 750-461and the versions 750-461/000-006 and 750-461/025-
000 calculate the resistance values of Pt100 sensors and output the data as
temperature values. The temperature values are displayed at a resolution of 1
digit per 0.1 °C in one word (16-bit). Temperature values below 0 °C are
represented in two's complement binary. As a result, 0 °C corresponds to the
numeric value 0x0000 and 100 °C to the numeric value 0x03E8 (dec. 1000). The
possible numeric range corresponds to the defined temperature range of −200 °C
to +850 °C for Pt100 sensors.
