750-461 2AI Pt100/RTD
Manual
Version 1.4.1
Pos: 32 /Alle Serien ( Allgemeine Module)/ Überschriften/Ebene 2/An schlussbeispiel e - Überschrift 2 @ 4\mod_124099 6036328_21.doc x @ 32010 @ 2 @ 1
6.2 Connection Examples
Pos: 33 /Serie 750 (W AGO-I/O-SYSTEM)/Wichtige Erläuteru ngen (alte Struktur) /Sicherheits- und sonstig e Hinweise/Hin weis/Hinweis: Gesc hirmte Signalleitungen verwenden! @ 7\mod_126572 3251019_21.docx @ 50140 @ @ 1
Use shielded signal lines!
Only use shielded signal lines for analog signals and I/O modules which are
equipped with shield clamps. Only then can you ensure that the accuracy and
interference immunity specified for the respective I/O module can be achieved
even in the presence of interference acting on the signal cable.
Pos: 34 /Serie 750 (W AGO-I/O-SYSTEM)/Anschließen/Anschl ussbeispiele/Ana logeingangskle mmen/Anschlussbeispie le 750-0461 @ 10\mod_129889 9541065_21.doc x @ 70317 @ 33 @ 1
6.2.1 2 × RTD, 2-Conductors
Figure 10: Example Connection 2 × RTD, 2-wire
