FL85-IIfeatures
Toassisttheoperatorinbecomingfamiliarwiththe
featuresoftheFL85,andtosupportdevelopmentof
operationalandmaintenanceproceduralknowledge,this
manualprovidesdetailedoperatingandmaintenance
instructions,aswellassafetyinformationandequipment
data.
1.Link:Thepivotpointbetweenthecarrierandthe
fellinghead.
2.Swingdamper:Useshydraulicuidtodampenthe
swingandfallofthetree.
3.Rotator:Hydraulic-drivenrotationofthefellinghead.
4.Tilt-bracket:AU-shapedbracketthatpivotsthe
fellingheadverticallyandhorizontally.
5.Tilt-bracketcylinder:Thiscomponentallowsthetree
tofallinacontrolledway.
6.Main-frame:Themainstructuralcomponentofthe
fellinghead;itincludesanintegratedoilreservoir.
7.Grapplecylinder:Thismovesthegrapplearmsback
andforth.
8.Singlegrapplearm:Thisarmtsbetweenthedouble
grapplearms;itisusedtoclampthetree.
9.Doublegrapplearm:Alsousedtoclampthetree,
thisarmtsoverandunderthesinglegrapplearm.
10.Main-sawchamber:Thishousesthemain-saw
assembly.
11.3/4”saw:Thisperformsthemainlength-cutting
operation.
