waratah FL85 - Tilt Bracket; Lubrication Oil Reservoir

Maintenance:Procedures
AM24480,0000359-19-29FEB16-1/1
AM24480,000035A-19-29FEB16-1/1
Tiltbracket
Approximatelyevery6-12months,ensureyouinspectthe
tiltbracketandcheckthecap-screwsandnutsconnecting
thelink(1)totherotator(2),andthoseconnectingthe
rotator(2)tothetiltbracket(3),aretightenedappropriately
anddonotshowsignsofdamageand/orexcessivewear.
Ifthesefastenersareloose,ortherearesignsofdamage
and/orwear,tighten,repair,orreplacethemasrequired.
1—Link
2—Rotator
3—Tiltbracket
1
2
3
XJ1199376—UN—12AUG15
Lubricationoilreservoir
Ensureyoucleanthelubricationoilreservoir’sstrainer
inthellcap(1),andthemagneticdrainplug(2),onan
annualbasis.
1—Fillcapandstrainer2—Magneticdrainplug
1
2
TX1044798—UN—26JUN08
3-3-4
090621
PN=52
