waratah FL85 - Felling Head Specifications

Miscellaneous:Specications
ContinuedonnextpageAM24480,0000365-19-06SEP21-1/2
Fellingheadspecications
TX1044913
F
G
60˚
60˚
E
A
B C D
TX1044913—UN—01JUL08
A—Centreoftheupperlink-pinto
thecenterofthelowerlink-pin
B—Centreofthelowerlink-pinto
thecentreofthetiltbracket
pin
C—Centreoftheupperlink-pin
tothebottomofthesaw-box
D—Overallheight
E—Fellingheadlength
F—Fellingheadwidth
G—Upperlengthwidth
ItemMeasurementSpecication
FL85FellingHead
A—Heightfromthecentreofthe
upperlink-pintothecenterofthe
lowerlink-pin
380mm
14.96”
B—Heightfromthecentreofthe
lowerlink-pintothecentreofthe
tiltbracketpin
1101.5mm
43.37”
C—Heightfromthecentreofthe
upperlink-pintothebottomofthe
saw-box
2053mm
80.83”
D—Overallheight2158mm
84.96”
E—Lengthofthefellinghead1443mm
56.81”
F—Widthofthefellinghead1658mm
65.28”
G—Upperlengthwidth149mm
5.88”
Totalweight1550kg
3440lb
