waratah FL85 - Check the Saw Bar Travel

Maintenance:InitialSet-up
AM24480,0000352-19-06SEP21-1/3
ContinuedonnextpageAM24480,0000352-19-06SEP21-2/3
Checkthesawbartravel
Thesawbartravelispoweredbybackpressureinthe
sawreturnline,whilethetravel-to-speedpressureis
proportionaltothesawmotorrpm.Asthesawmotor
slowsdown,thetravelspeedslowsdown,preventingthe
sawchainfrom‘stallingout’.
1.Closethegrapplearms.
2.Placethefellingheadinthe‘tilt-up’position,securely
ontheground.
3.Shutdownthecarrier.
CAUTION:Asthefellingheadcanmoveor
functionunexpectedly,youshouldalwaysmake
surethecarrieriscompletelyshutdown,with
thefellingheadplacedsecurelyonat,level
ground.Failingtofollowthisprocesscan
increasetheriskofseriousinjuryordeath.
4.Removethesawbarcover(1).
1
TX1044994—UN—02JUL08
1—Sawbarcover
5.Removethehose(3)andtting(2).
2—Fitting3—Hose
2
3
TX1045005—UN—02JUL08
3-2-4
090621
PN=47
