waratah FL85 - Charging the Air Tank

Maintenance:InitialSet-up
AM24480,0000350-19-06SEP21-1/1
Chargingtheairtank
1.Removethelargeairinletcap(2)fromtheairinlet(1).
2.Removethesmallairinletcap(3)fromthevalve.
3.Connecttheairpumpnozzle(4)tothevalve;charge
theairtanktospecication.
Specication
Airtankmaximum
pressure..........................................................1379kPa
13.8bar
200psi
4.Removetheairpumpnozzlefromthevalve.
5.Re-installthesmallairinletcap.
6.Re-installthelargeairinletcap.
IMPORTANT:Ensureyoureplacebothinletcaps
properly;debriscanbuildupintheair
inlet,allowingairtoleakfromtheairtank.
Withouttheproperairpressure,thesaw
barwillnotfunctionproperly.
1—Airinlet
2—Largeairinletcap
3—Smallairinletcap
4—Airpumpnozzle
2
1
TX1044693—UN—25JUN08
3
1
TX1044695—UN—25JUN08
4
1
TX1044697—UN—25JUN08
