waratah FL85 - Adjust the Saw Bar Travel Limiter

Maintenance:InitialSet-up
AM24480,0000352-19-06SEP21-3/3
AM24480,0000353-19-06SEP21-1/1
6.AttachgaugeJT05473(5)tothesawbartravelport(4);
ensurethegaugeisvisiblefromtheoperator’sseat.
7.Startthecarrierandoperatethesawfunction.
IMPORTANT:Beawarethatthesawmotorwillbe
damaged;onlyoperatethesawfunctionduring
thetest.Ifthesawmotorisdamaged,you
mustrepairorreplaceitasrequired.
8.Ensurethesawbartravelpressureiswithin
specication.
Specication
Sawbartravelpressure............................................5000—5500kPa
50—55bar
725—800psi
9.Shutdownthecarrier.
CAUTION:Asthefellingheadcanmoveor
functionunexpectedly,youshouldalwaysmake
surethecarrieriscompletelyshutdown,with
thefellingheadplacedsecurelyonat,level
ground.Failingtofollowthisprocesscan
increasetheriskofseriousinjuryordeath.
10.Removethegauge(5).
4
5
TX1045004—UN—02JUL08
4—Sawbartravelport5—Gauge
11.Re-installthetting(2)andhose(3).
12.Re-installthesawcover(1).
Adjustthesawbartravellimiter
1.Thelengthofsawbartravellimiter(A)ispre-setto
specication.
Specication
Sawbartravellimiter
length............................................................631mm
24.84”
2.Loosenthenuts(3)onthelimiter.
3.Increaseordecreasethelengthofthesawbartravel
limiter,settingittowithinspecication.Increasingthis
lengthwillincreasethesizeofthesawbar’sswing;
reducingthislengthwilldecreasethesizeofthesaw
barswing.
Specication
Rangeofthesawbar
travellimiterlength...................................................616—641mm
24.25—25.25”
4.Re-tightenthenuts(3).
1
3
2
3
A
TX1044821—UN—27JUN08
1—Sawbartravellimiter
2—Sawbartravellimiter
Adjuster
3—Nut(x2)
A—631mm(24.84”)
3-2-5
090621
PN=48
