Greaselocations
NOTE:Useamineraloil-basedgreasethatis
thickened/mixablewithalithiumsoap.According
toISO6743–9,greaseshouldbeclassied
asL-XCCIB2;thereshouldbeamaximum
molybdenumdisuldecontentlevelofthreepercent,
abaseuidviscosityof170-220cStat40-degrees
Centigrade,andanNLGIclass1-2.
Fellingheadlubricationttings
Dependingontheworkingconditions,youshouldlubricate
thefellingheadatleastonceaweekviaall19lubrication
points.
1—Upperlink(x3lubrication
ttings)
2—Tilt-frame(x2lubrication
ttings)
3—Tiltcylinders(x4lubrication
ttings)
4—Femalegrapplearm(x2
lubricationttings)
5—Malegrapplearm(x2
lubricationttings)
6—Grapplecylinder(x2
lubricationttings)
7—Push-rod(x2lubrication
ttings)
8—Sawunit(x2lubrication
ttings)
8
1
1
3
2
5
4
1
8
7
6
TX1044820—UN—27JUN08
Greasepointlocations
1
3
1
1
8
6
7
4
2
5
XJ1199375—UN—12AUG15
GreasepointlocationsSeriesII
