waratah FL85 - Additional Metric Cap-Screw Torque Values

Miscellaneous
AM24480,0000360-19-29FEB16-1/1
Additionalmetriccap-screwtorquevalues
METRICCAP-SCREWTORQUEVALUES
Unlessotherwisespecied,thetoleranceis±10%
T-BoltH-BoltM-Bolt
Nomi-
nalDiaN·mlb-ftN·mlb-ftN·mlb-ft
82921201510
7
10634645332015
121088088653425
141761301371015440
162651952061527858
1839228929421711887
20539398392289167125
22735542539398216159
24931687686506274202
27137210121029759392289
301911141014211049539398
332548189019111410735542
363136231424011772931687
CAUTION:Onlyusemetrictoolswithmetric
hardware;othertoolsmightnottproperly,which
maycausethetooltoslip,resultingininjury.
DONOTusethesevaluesifadifferenttorquevalueor
tighteningprocedureisgivenforaspecicapplication.
Thetorquevalueslistedareforgeneraluseonly.
Ensureyoucheckthetightnessoffastenersperiodically.
Asshear-boltsaredesignedtofailunderpre-determined
loads,youshouldalwaysreplaceshear-boltswithan
identicalgrade.
Onlyreplacefastenerswiththoseofthesamegradeor
higher;whereahigher-gradefastenerisused,ensure
onlytightenthemtothestrengthoftheoriginal.
T6873AA—UN—15APR13T6873AB—UN—18OCT88T6873AC—UN—18OCT88
Ensurefastenerthreadsarecleanandthatyoustart
thread-engagementproperly;takingthesestepswill
minimisetheriskoffastenersfailingwhentheyarebeing
tightened.
Forcap-screwswithlock-nuts,youshouldonlytighten
themtoapproximately50percentofthevalueshown
inthechart.
4-1-4
090621
PN=59
