Miscellaneous:Specications

AM24480,0000365-19-06SEP21-2/2

ItemMeasurementSpecication

Sizeofthesawbarandsawchain3/4”pitch,high-speed

Maximumgrippingdiameter1100mm

43.30”

Minimumgrippingdiameter50mm

2.0”

Nominalcuttingcapacity850mm

33.5”

TypeofchaintensionAutomatic

TypeofchainlubricationProportional

TypeofheadrotationContinuous

Hydraulicpressureandow

Grapplepressure24821kPa

248bar

3600psi

Grappleopentime5.5sec.

Grappleclosedtime3.7sec.

Tiltpressure18961kPa

189bar

2750psi

Tilt-uptime2sec.

Rotatorpressure24821kPa

248bar

3600psi

Rotatorowrate132L/min

35gpm

Swingdamperpressure18961kPa

189bar

2750psi

4-4-3

090621

PN=67
