Miscellaneous

AM24480,000035E-19-29FEB16-2/2

Tightenplasticinsert-orcrimpedsteel-typelock-nutsto

approximately50percentofthedrytorqueshowninthe

chart,andtightentoothed-orserrated-typelock-nutsto

thefulltorquevale.Thetorquevalueshouldbeappliedto

thenut,nottothebolt-head.

4-1-2

090621

PN=57
