14 Installation
1
1
Installation
The Waters
®
996 Photodiode Array (PDA) Detector operates in any standard laboratory
environment. The detector requires electrical power, sample and waste fluidic lines, and
the Millennium®
32
Workstation. Optional connections on the detector rear panel allow
communication with chart recorders, data integrators, and other instruments that are not
compatible with Millennium software control.
1.1 Installation Site Requirements
Install the Waters 996 PDA Detector (Figure 1-1) at a site that meets the specifications
listed in Table 1-1
.
Table 1-1 Site Requirements
Factor Specification
Ambient temperature 4 to 40° C (39 to 104° F)
Relative humidity 20 to 80 percent,
noncondensing
Bench space Width: 11.5 in. (29 cm)
Depth: 24 in. (61 cm)
Height: 8.125 in. (22
cm)
Bench support Capable of supporting
31.5 pounds (14.3 kg)
Clearance At least 4 in. (10 cm) on
the back and left sides
for ventilation
