96
Secure columns within the heater/cooler compartment using adjustable
column clamps attached to the column rail. You can add multiple clamps to
the rail that are held in place when the column is inserted. The column clamps
are designed to hold onto the compression screw threads, to accommodate the
columns of various manufacturers. They do not damage the screw threads.
ACQUITY UPLC 30-cm CHC column configurations:
Quantity Description
1 300-mm length column: 7.8-mm ID, or less, with a column guard
of 20-mm, or less
2 300-mm length column: 7.8-mm ID, or less, with column guards
of 20-mm, or less
4 150-mm length column: 7.8-mm ID, or less, without column
guards
6 50-mm length column: 7.8-mm ID, or less, without column
guards
Column guard
Column
Column clamp
Column rail
Column clamp
