Preparing the column compartments 97
Tubing retainers provided along the left-hand side, bottom, and top of the
column compartment hold tubing in place. Use these retainers to organize
tubing and keep it orderly.
Tubing retainers:
The heater or heater/cooler column compartment functions only when you can
properly close the door. The door’s gasket and hinge assembly allow tubing to
pass through undamaged.
To activate auxiliary column manager units:
1. Click the Enabled check box corresponding to the auxiliary column
manager units you want to activate.
Restriction: When the icon of an auxiliary column manager is
unavailable for selection, the software does not detect the device.
2. Click OK.
Caution: To avoid causing the compartment door’s gasket to fail or the
door to spontaneously spring open, do not route tubing out the bottom of
the door.
