104
14. Align the leak sensor’s T-bar with the slot in the side of the leak sensor
reservoir, and slide the leak sensor into place.
15. If you detached the connector from the front of the instrument, reattach
it, and power-on the sample manager.
16. In the ACQUITY UPLC Console, select Sample Manager FTN from the
system tree.
17. In the sample manager information window, click Control > Reset SM,
to reset the sample manager.
To resolve a 30-cm column heater leak sensor error:
1. In the ACQUITY UPLC Console’s Leak Sensors dialog box, determine
which of the sample manager’s two leak sensors detected a leak.
2. If the message reads “Leak Detected (Column)”, open the 30-cm column
heater’s door.
3. Locate the source of the leak, and make the repairs necessary to stop it.
T-bar
Leak sensor
installed in
reservoir
Slot in leak
sensor reservoir
