134
2. Disconnect the inlet tubing from injector port 6 of the sample manager.
3. Open the column heater door.
4. Using the Phillips screwdriver, loosen the two screws that fasten the
column stabilizer assembly to the column compartment tray.
5. Remove the column stabilizer assembly from the thermal gasket.
6. Using the 1/4-inch and 5/16-inch open-end wrenches, disconnect the
compression fitting that attaches the column stabilizer assembly to the
optional in-line filter or to the column, and then remove the column
stabilizer assembly.
7. Firmly press the replacement column stabilizer assembly into the
thermal gasket. Ensure that the thermal gasket uniformly envelops the
sides of the column stabilizer and does not bunch beneath it.
Location of
column-stabilizer-inlet tubing
Column-stabilizer-
inlet tubing
Threaded holes for
Phillips screws
Thermal gasket visible along
both sides of stabilizer
