Compression screw
Lock ring
Ferrule
End of lock ring with larger inside diameter (ID)
Tighten the fitting finger-tight.
2.5.1.6
5/16-24 fitting with filter and stainless steel lock ring
First use or re-installed
Compression screw
Lock ring
Ferrule and filter
End of lock ring with larger inside diameter (ID)
Tighten the fitting finger-tight.
2.5.1.7
Stainless steel (gold-plated) fitting with long flats and 2-piece stainless-steel
ferrule
First use
