Placement of collet and compression-screw multi-tool and 5/16-inch open-end
wrench
Collet and compression-screw multi-tool
Column or column in-line filter
5/16-inch open-end wrench
Tip: When reinstalling the fitting,
• examine the collet and ferrule for damage, and replace them, if necessary;
• always loosen the collet before re-connecting the reusable finger-tight fitting.
Re-installed tightening
2.5.1.12
Dual-threaded, finger-tight fitting with loose ferrule
First use or re-installed
