Benchmark with Edge [I]: Operation-Maintenance Manual
SECTION 2: OPERATION
OMM-0145_D • GF-218 • 11/2/2020 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 18 of 213
2.3.3.2 Main Menu → Diagnostics → Front Panel
Main Menu → Diagnostics → Front Panel
Touchscreen Display Test
On/Off
Starts the Touchscreen Display Test.
Touchscreen Test
On/Off
Starts the Touchscreen Test.
Status Light Test
On/Off
Starts the Status Light Test.
Keypad and Switch Test
On/Off
Starts the Keypad and Switch Test.
2.3.3.3 Main Menu → Diagnostics → Analog Outputs and Relays
Main Menu → Diagnostics → Analog Outputs and Relays → Relays
Ignition Relay
Enable/Disable
Enables/Disables the Ignition Relay.
Blower Relay
Enable/Disable
Enables/Disables the Blower Relay.
Pump Relay
Enable/Disable
Enables/Disables the Pump Relay.
Aux Relay
Enable/Disable
Enables/Disables the Aux Relay.
Fault Relay
Enable/Disable
Enables/Disables the Fault Relay.
Main Menu → Diagnostics → Analog Outputs and Relays → Analog Outputs
Valve
Read/Adjust
Adjustable display of the A/F valve Position.
Blower
Read/Adjust
Adjustable display of the Blower.
2.3.3.4 Main Menu → Diagnostics → Subsystems
Main Menu → Diagnostics → Subsystems → Air Fuel Valve Stepper Motor
Auto Stroke
Toggle
Initiates A/F cycle, 0 to 100 to 0%
Valve Position In
Adjust
Manual adjustment of A/F Valve 0 to 100%.
Main Menu → Diagnostics → Subsystems → Blower
Profile
Select
Select the profile to run (default = Profile 1).
Profile Run
Enable/Disable
Enables running the selected profile.
Blower
Numeric Entry
Manually adjust the Blower’s voltage.
Main Menu → Diagnostics → Subsystems → Ignition
Ignition Spark
Enable/Disable
Enables testing the unit’s ignition spark.
Spark Current
Read Only
The current Spark Current.
2.3.3.5 Main Menu → Diagnostics → System
Main Menu → Diagnostics → System → Pre-Start Up
Pre-Start Up Mode
Enable/Disable
Enables Pre-Start Up Mode, a test of various system
components without firing the unit.
Valve Position Out
Read Only
The current A/F valve position.
Blower (voltage)
Read Only
The current Blower voltage.
Blower (RPM)
Read Only
The current Blower RPM.
Spark Current
Read Only
The current Spark Current.
Flame Strength
Read Only
The current flame strength.
Gas pressure
Read Only
The current gas pressure.
Main Menu → Diagnostics → System → Versions
Serial Number
Read Only
The unit’s serial number.
Software Version
Read Only
The Controller’s software version.
