Benchmark with Edge [I]: Operation-Maintenance Manual
SECTION 2: OPERATION
OMM-0145_D • GF-218 • 11/2/2020 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 19 of 213
Engineering Version
Read Only
The Controller’s Engineering software version.
Graphic Data Version
Read Only
The Controller’s graphic version.
Display Version
Read Only
The Controller’s display version.
I/O Board Version
Read Only
The I/O board version.
Touch Version
Read Only
The touch screen version.
Bluetooth Version
Read Only
The Bluetooth version.
Framework Version
Read Only
The Framework version.
Bootloader version
Read Only
The Bootloader version.
Display BL Version
Read Only
Display Bootloader version.
I/O PCB BL Version
Read Only
I/O Board PCB Bootloader version.
2.3.3.6 Main Menu → Diagnostics → Comm & Network
Main Menu → Diagnostics → Comm & Network → IP Network
Unit IP Address
Read Only
The unit’s IP address.
Subnet Mask
Read Only
The unit’s subnet mask address.
Gateway IP Address
Read Only
The unit’s gateway IP address.
DSN 1
Read Only
The unit’s DSN 1 address.
DSN 2
Read Only
The unit’s DSN 2 address.
Unit MAC Address
Read Only
The unit’s MAC address.
Network Status
Read Only
The unit’s current network status.
Main Menu → Diagnostics → Comm & Network → BAS
BAS
Read Only
The Building Automation System protocol.
Communication
Address
Read Only
The unit’s BAS address.
Device Instance
Read Only
The unit’s Device Instance within BAS.
Unit IP Address
Read Only
The unit’s IP address on the network.
Unit MAC Address
Read Only
The unit’s MAC address within BAS.
Last Command
Received
Read Only
The last command received by the unit.
BAS IP
Read Only
If Security is enabled, this is the IP of the BAS system
that the unit can only communicate with.
Network Status
Read Only
The unit’s BAS network’s current status.
Main Menu → Diagnostics → Comm & Network → onAER
Unit IP Address
Read Only
The unit’s IP address.
Upload Time
Read Only
Frequency at which the unit transmits data to onAER
Test Setup
Enable
Initiates test o onAER functionality.
Test Heartbeat
Enable
Initiates test of the onAER heartbeat.
Main Menu → Diagnostics → Comm & Network → USB Storage
Status
Read Only
Status of the USB device.
Serial Number
Read Only
The serial number of the USB device.
Size
Read Only
The size of the USB device.
Available Space
Read Only
The amount of free space on the USB device.
