11 Technical Data
Description
Value
General
Dimensions
195mm * 135mm * 60mm (L*B*H)
Weight
700 Gramm
Operating temperature
-15°C bis 55°C
Storage temperatur
-20°C bis 75°C
Safety distance compass
mind. 40 cm
Power Specification
Board voltage
12V DC / 24V DC
Operating voltage range
9,6 bis 31,2V DC
Input
2,9W bei 12V DC
Current consumption
2A (Senden), -240mA (Stand.) bei 12V DC
GNSS Specification
GPS/GNSS Receiver (internal)
72 Channel GNSS Receiver
# GPS
# GLONASS
# GALILEO
External Connections
Interfaces
3x NMEA0183 IN
3x NMEA0183 OUT
NMEA2000
Connections (standard version)
USB
18 pin plug
NMEA2000 socket
external GPS antenna (BNC)
VHF antenna connection (SO239)
VHF connection (TNC)
