CFW701 | 27
Keypad (HMI) and Basic Programming
English
The HMI supplied with the product can also be used for remote command of the inverter. In
this case, use a cable with male and female D-Sub9 (DB-9) connectors wired pin to pin (mouse
extension type) or a market standard Null-Modem cable. Maximum length of 10 m (33 ft). It is
recommended the use of the M3 x 5.8 standoffs supplied with the product. Recommended
torque: 0.5 N.m (4.5 lbf.in).
Use the keypad frame accessory to assembly the keypad on the panel door or control table
(see Section 7.2 ACCESSORIES on page 38, or perform the drilling as shown in Figure A.5
on page 144).
NOTE!
A list of parameters is supplied with the product, for additional information
on each parameter refer to the CFW701 programming manual available for
download on website: www.weg.net.
