WEG CFW701 - Electrical;General Specifications

CFW701 | 41
Technical Specifications
English
8.2 ELECTRICAL/GENERAL SPECIFICATIONS
Table 8.1: Electrical/general specifications
CONTROL METHOD  Voltage source.
 Type of control:
- V/f (Scalar).
- VV W: Voltage Vector Control.
- Sensorless vector control (without encoder).
 PWM SVM (Space Vector Modulation).
 Full digital (software) current, flux, and speed regulators.
Execution rate:
- current regulators: 0.2 ms (5 kHz).
- flux regulator: 0.4 ms (2.5 kHz).
- speed regulator / speed measurement: 1.2 ms.
OUTPUT
FREQUENCY
 0 to 3.4 x rated motor frequency (P0403). The rated motor frequency
is programmable from 0 Hz to 300 Hz in the V/f and V VW modes and
from 30 Hz to 120 Hz in the vector mode.
 Maximum output frequency limit according to the switching frequency:
- 125 Hz (switching frequency = 1.25 kHz).
- 200 Hz (Switching frequency = 2 kHz).
- 250 Hz (switching frequency = 2.5 kHz).
- 500 Hz (switching frequency ≥ 5 kHz).
PERFORMANCE SPEED
CONTROL
V/f (Scalar):
 Regulation (with slip compensation): 1 % of the rated speed.
 Speed variation range: 1:20.
VVW:
 Regulation: 1 % of the rated speed.
 Speed variation range: 1:30.
Sensorless:
 Regulation: 0.5 % of the rated speed.
 Speed variation range: 1:100.
PERFORMANCE TORQUE
CONTROL
 Range: 10 to 180 %, regulation: ±5 % of the rated torque (with encoder).
 Range: 20 to 180 %, regulation: ±10 % of the rated torque (sensorless
above 3 Hz).
USER’S POWER
SUPPLIES
(CC701 board)
REF
(XC1:21-24)
 10 V ± 10 % power supply to be used with the potentiometer at the
analog inputs.
 Maximum output current: 2 mA.
+5 V
(XC1:1-8)
 5 V ± 5 % power supply.
 Maximum output current: 160 mA.
+24 V  24 V ± 10 % power supply to be used with the digital inputs/outputs.
 Maximum output current: 500 mA.
INPUTS
(CC701
board)
ANALOG  3 differential inputs.
 Resolution: 11 bits + signal.
 Input levels: (0 to 10) V, (-10 to 10) V, (0 to 20) mA or (4 to 20) mA.
(1)
 Impedance: 400 kΩ for the voltage input, 500 Ω for the current input.
 Maximum input voltage: ± 15 V.
 Programmable functions.
DIGITAL  8 isolated digital inputs.
 24 Vdc (High level ≥ 10 V, Low level ≤ 2 V).
 Maximum input voltage: ± 30 Vdc.
 Input impedance: 2 kΩ.
 Active high or active low input selectable by jumper (simultaneous
selection for all inputs).
