42 | CFW701
Technical Specifications
English
OUTPUTS
(CC701
board)
ANALOG 2 non isolated outputs.
Voltage (0 to 10 V) or current (0/4 mA to 20 mA) output.
Maximum load: RL ≥ 10 kΩ (voltage) or RL ≤ 500 Ω (current).
Resolution: 10 bits.
Programmable functions.
RELAY 2 relays (NO).
Maximum voltage: 240 Vac / 30 Vdc.
Maximum current: 0.75 A.
Programmable functions.
TRANSISTOR 3 open collector isolated digital outputs (with the same reference as
the 24 V power supply).
Maximum current: 80 mA.
Maximum voltage: 30 Vdc.
(2)
Programmable functions.
Note: When the load of the digital output is fed by an external power
supply, the output status remains indefinite until the internal 24 V
power supply becomes stable.
SAFETY PROTECTION Output overcurrent/short-circuit.
Under/Overvoltage.
Phase loss.
Overtemperature of the heatsink/internal air.
IGBTs overload.
Motor overload.
External fault / alarm.
CPU or memory fault.
Output phase-ground short-circuit.
INTEGRAL
KEYPAD
(HMI)
STANDARD
KEYPAD
9 operator keys: Start/Stop, Up arrow, Down arrow, Direction of
rotation, Jog, Local/Remote, BACK/ESC and ENTER/MENU.
LCD display.
View/edition of parameters.
Indication accuracy:
- current: 5 % of the rated current.
- speed resolution: 1 rpm.
Possibility of remote mounting.
USB communication port.
(3)
ENCLOSURE IP20 Frame sizes A, B and C inverters without the top cover and Nema1 kit.
Frame size E inverters without Nema1 kit.
NEMA1/IP20 Frame size D inverters without IP21 kit.
Frame size E inverters with Nema1 kit (KN1E-01 or KN1E-02).
IP21 Frame sizes A, B and C inverters with top cover.
NEMA1/IP21 Frame sizes A, B and C inverters with top cover and Nema1 kit.
Frame size D inverters with IP21 kit.
IP54 Rear of the inverter with degree of protection IP20 (external part for
flange mount)
(4)
.
IP55 Frame sizes B, C, D and E.
(1) AI3 only has (0 to 20) mA and (4 to 20) mA input levels.
(2) Transistor outputs have an internal freewheel diode to +24 V
(3) Available from the serial number 1023801859.
(4) Models 180 A and 211 A with 220 / 230 V and 380...480 V power supply, and models 125 A and 150 A with 500...600 V
power supply require special hardware H1.
