Option Kits and Accessories
English
7 OPTION KITS AND ACCESSORIES
7.1 OPTION KITS
Some models cannot incorporate all available option kits. Refer to Table 2.2 on page 6 for
a detailed description of the option kits that are available for each inverter model.
7.1.1 Dynamic Braking IGBT (only for frame size E and 500...600 V models of
frame size D) - CFW701E...DB...
Refer to Item 3.2.3.3 Dynamic Braking (standard built-in for frame sizes A, B, C and D and
optional built-in for frame size E - CFW701...DB...) on page 15, for more details about the
Dynamic Braking.
7.1.2 Nema1 Protection Degree (only for frame sizes A, B, C and E and
500...600 V models of frame size D) - CFW701...N1...
Inverter with Nema1 enclosure. Refer to Figure B.2 on page 174. These inverters have the
KN1X-02 kit (refer to Section 7.2 ACCESSORIES on page 38).
7.1.3 IP55 Protection Degree (only for frame sizes B and C) - CFW701...55...
Inverter with IP55 enclosure. Refer to Figure A.10 on page 149. These inverters have the
PCSC-03 kit (refer to Section 7.2 ACCESSORIES on page 38).
7.1.4 IP21 Protection Degree (only for frame sizes A, B and C) - CFW701...21...
Inverter with IP21 enclosure. Refer to Figure A.9 on page 148. These inverters have the
KIP21X-01 kit (refer to Section 7.2 ACCESSORIES on page 38).
7.1.5 STO Function - CFW701...Y1...
The STO function complies with the requirements of category 3 (PL d) according to EN ISO
13849-1, SIL CL 2 according to IEC 61800-5-2 / IEC 62061 / IEC 61508 and can be used in
applications up to category 3 (PL d) according to EN ISO 13849-1 and SIL 2 according to IEC
62061 / IEC 61508. Refer to the guide supplied with the product for more information.
NOTE!
 It is not possible to assemble the top cover on inverters of frame size A that
have optional safety stop. Thus, it is not possible to raise the protection level
of these inverters to IP21 or Nema1.
 STO function is incompatible with fire mode and bypass functionalities.
7.1.6 24 Vdc External Control Power Supply - CFW701...W1...
The use of this option kit is recommended with communication networks (Profibus, DeviceNet,
etc.), since the control circuit and the network communication interface are kept active (with
power supply and responding to the network communication commands) even in the event of
main power supply interruption.
