CFW701 | 39
Option Kits and Accessories
English
Table 7.1: Accessory models
WEG
Part
Number
Name Description Slot
Identification
Parameters
- P0028
Control Accessories
11 5 11 558 USB-RS-485/RS-422 USB-RS-485/RS-422 Interface kit. - -
Flash Memory Module
11355980 MMF-02 FLASH memory module. 5 --xx
(1)
Expansion Module
11402038 CCK-01 Output relays module. - -
Stand-alone Keypad, Blank Cover, and Frame for Remote Mounted Keypad
11829628 HMI-03 CFW701 stand-alone keypad (HMI).
(2)
HMI -
11829782 RHMIF-03 Remote keypad frame kit (IP56). - -
10950192 1 m HMI CAB-RS _1M 1 m serial remote keypad cable set. - -
10951226 2 m HMI CAB-RS _2M 2 m serial remote keypad cable set. - -
10951223 3 m HMI CAB-RS _3M 3 m serial remote keypad cable set. - -
10951227 5 m HMI CAB-RS _5M 5 m serial remote keypad cable set. - -
10951240 7.5 m HMI CAB-RS _7.5M 7.5 m serial remote keypad cable set. - -
10951239 10 m HMI CAB-RS _10M 10 m serial remote keypad cable set. - -
11010298 HMID-01 Blank cover for the keypad slot. HMI -
Miscellaneous
11401877 KN1A-02 Nema1 kit for frame size A inverter.
(3)
- -
11401938 KN1B-02 Nema1 kit for frame size B inverter.
(3)
- -
11401857 KN1C-02 Nema1 kit for frame size C inverter.
(3)
- -
10960842 KN1E-01 Nema1 kit for models 105 A and 142 A of
frame size E inverter.
(3)
- -
10960850 KN1E-02 Nema1 kit for models 180 and 211 A of
frame size E inverter.
(3)
- -
11401939 KIP21A-01 IP21 kit for frame size A inverter. - -
11401941 KIP21B-01 IP21 kit for frame size B inverter. - -
11401940 KIP21C-01 IP21 kit for frame size C inverter. - -
11010264 KIP21D-01 IP21 kit for frame size D inverter. - -
11010265 PCSA-01 Kit for power cables shielding - frame size A. - -
11010266 PCSB-01 Kit for power cables shielding - frame size B. - -
11010267 PCSC-01 Kit for power cables shielding - frame size C. - -
11119781 PCSD-01 Kit for power cables shielding - frame size D
(included in the standard product).
- -
10960844 PCSE-01 Kit for power cables shielding - frame size E
(included in the standard product).
- -
12705234 PCBC-01 Kit for power cables shielding - frame sizes
B and C with degree of protection IP55.
- -
13231750 PCSD-02 Power cable shielding kit for frames D with
IP55 degree of protection.
- -
10960847 CCS-01 Kit for control cables shielding (included in
the standard product).
- -
11829630 CONRA-03 CFW701 Control Rack (includes the CC701.
CDE control board and it is supplied with the
product).
- -
10790788 DBW030380D3848SZ 380...480 Vac dynamic braking module. - -
10794631 DBW030250D5069SZ 500...690 Vac dynamic braking module. - -
Notes:
(1) The identification of the MMF-02 module is presented in the bit 6 of the parameter P0028. Refer to CFW701 programming
manual.
(2) Use DB-9 pin, male-to-female, straight-through cable (serial mouse extension type) for connecting the keypad to the
inverter or Null-Modem standard cable. Maximum cable length: 10 m (33 ft).
Examples:
- Mouse extension cable - 1.80 m (6 ft); Manufacturer: Clone.
- Belkin pro series DB9 serial extension cable 5 m (17 ft); Manufacturer: Belkin.
- Cables Unlimited PCM195006 cable, 6 ft DB9 m/f; Manufacturer: Cables Unlimited.
(3) Refer to Figure B.2 on page 174.
