Weidmüller PrintJet PRO - Index

Appendix
100
5661290000/00/06.08
Index
Figure Page
Figure 1
Insertion instructions 12
Figure 2 Warning label on device 13
Figure 3 Printer components 18
Figure 4 Connections 19
Figure 5 Enclosure 19
Figure 6 Ink-cartridge lid 19
Figure 7 Loader and maintenance cover 2 (ink waste pad) 19
Figure 8 Maintenance cover 1 (printing system) 20
Figure 9 Openings 20
Figure 10 Input (loader) 20
Figure 11 Output 20
Figure 12 Display 21
Figure 13 Display 23
Figure 14 Turning the display 23
Figure 15 Maintenance cover 23
Figure 16 Necessary clearance space 26
Figure 17 Inserting the output rail 28
Figure 18 Ink cartridge 29
Figure 19 Ink cartridge and ink-cartridge carrier 29
Figure 20 Inserted ink cartridge 29
Figure 21 Inserting the ink-cartridge carrier 30
Figure 22 Color System / Black System 30
Figure 23 Language selection – software installation 34
Figure 24 Operating System for printer driver 35
Figure 25 Licence agreement 36
Figure 26 Connecting the printer 36
Figure 27 Installing the printer driver 37
Figure 28 Automatic recognition of the USB connection 37
Figure 29 Standard printer 38
Figure 30 Status monitor 38
Figure 31 Installation of printer driver successful 39
Figure 32 LAN settings 40
