Initial commissioning
26
5661290000/00/06.08
4.1 Unpacking
Carefully take all parts out of the packaging. Always use two people to move the printer and make use of the
grips available on the device.
NOTE
Please keep the original packaging in case you need to re-ship the printer in the future!
Figure 16 Necessary clearance space
A 250 mm
B 200 mm output rail
C 100 mm
D 250 mm
E 100 mm
F Grips
The figure shows the necessary clearance room for the optimal insertion and removal of the MultiCards, and
for sufficient air circulation.
NOTE
Run through the commissioning procedure as detailed in the instructions before turning on the
printer!
A B
C
D
E
F
F
