Weidmüller PrintJet PRO - Connections; Enclosure

Printer description
5661290000/00/06.08
19
3.2.2 Connections
A B C
Figure 4 Connections
A. Mains power supply connection
CAUTION!
Verify the power supply voltage!
B. Fuses
Fuse 1 Load circuit
Fuse 2 Supply circuit
C. Printer connections
USB port
Ethernet port
3.2.3 Enclosure
A A
Figure 5 Enclosure
A Recessed grips
Figure 6 Ink-cartridge lid
Figure 7 Loader and maintenance cover 2
(ink waste pad)
